XFP, 10GBase-LR, DDM, 40km, Low-Band CWDM 1270nm-1450nm, 15dB, SM

XFP, 10GBase-LR, DDM, 40km, Low-Band

CWDM 1270nm-1450nm, 15dB, SM

Product nr: XFP-ER-CxxL
Show variants as list
Product
DescriptionTechnical info
Description
APPLICATIONS
• IEEE 802.3ae 10GBASE-LR 10.3125 Gb/s
• CWDM Metro Systems
• IP Core Networks

FEATURES
• Compatible with XFP MSA Rev. 4.5
• 10 CWDM lambdas (l): 1270 nm – 1450 nm
• Compliant to IEEE 802.3ae 10GBASE-LR at 10.3125 Gbit/s
• Up to 40 km transmission on 9/125 SM fiber G.652
• 12 dB link budget
• Hot pluggable 30 pin connector
• uncooled DFB laser
• Duplex LC-connector interface
• Compliant with the EU RoHS 6 Environmental Requirements

Technical info

Product information

Form factor XFP
Protocol / bit rate 10 Gigabit Ethernet
Media type Singlemode
Reach (dB) 12
Reach (km) 40
Wavelength (nm) CWDM
DDM Yes
Connector LC Duplex
