DescriptionTechnical info
Description
APPLICATIONS
• 1000Base Ethernet
• Fibre Channel
• CWDM Systems

FEATURES
• 18 CWDM wavelengths (λ): 1271 nm to 1611 nm
• Up to 80 km transmission with PIN receiver (24 dB)
• Hot-Pluggable SFP footprint LC Optical Transceiver
• Small Form-Factor Pluggable (SFP) MSA compatible
• SFF-8472 Digital Diagnostic Function
• Fully compliant to ITU G.694.2 & G.695
• operating temperature 0ºC to 70ºC

Technical info

Product information

Form factor SFP
Protocol / bit rate
  • Gigabit Ethernet
  • CPRI/OBSAI 1.228 - 3.072 Gbps
Media type
  • Singlemode
  • Multimode
Reach (dB) 24
Reach (km) 80
Wavelength (nm) CWDM
DDM Yes
Connector LC Duplex
