Fiberworks 4 ch. CWDM Mux+Demux for 100G

1271-1331 nm low loss + 1550WB, LC/UPC

Product nr: F-CMUX-4+1-2733LL-LU
Product
DescriptionTechnical infoAccessoriesAlternatives
Description
FEATURES
- Coarse WDM in compliance with ITU-T G.694.2
- 4 CWDM channels (1271, 1291, 1311, 1331 nm)
- Low loss (IL mux+demux typ. 1,6 dB, max 2,0 dB) for use with 100G single lambda
- Upgrade port for additional CWDM or DWDM channels
- Can be used to split 40GBASE-LR4 or 100GBASE-CWDM4 in four channels
- Based on thin film optics with epoxy free optical path
- Protocol transparent (support 1G, 10G etc.)
- Two modules fit in 1U in 19" rack
- LC/UPC connectors

Technical info

Product information

Form factor Fiberworks
Line fiber Double (fiber pair, mux+demux)
Channel count 4
OADM No, mux/demux
Expansion port Yes, 1550WB
Monitor port No
Connector type Straight (UPC, PC)
Connector LC/UPC
