SFP, 1.25 Gbps GigE, DDM, 80km 1550nm, 24dB, SM/MM

SFP, 1.25 Gbps GigE, DDM, 80km

1550nm, 24dB, SM/MM

DescriptionTechnical info
• 1000Base Ethernet
• 1G Fibre Channel
• Compatible with Small-Form Pluggable (SFP) MSA
• SFF-8472 Digital Diagnostic Function
• Compatible with IEEE 802.3z
• Compatible with ANSI specifications for Fibre Channel
• Dual data-rate of 1.25 Gb/s and 1.6025 Gb/s operation
• Operating wavelength at 1550 nm
• 80 km transmission with 9/125 µm SM fiber
• Duplex LC connector type
• Compatible with FCC 47 CFR Part, Class B Electromagnetic Interference (EMI)
• Compatible with IEC 61000-4-2 and GR-1089-CORE Electrostatic Discharge (ESD)
• +3.3V single power supply
• Operating temperature 0ºC to 70ºC
• Compliant with EU RoHS 6 Environmental Requirements
Technical info

Product information

Form factor SFP
Protocol / bit rate Gigabit Ethernet
Media type
  • Singlemode
  • Multimode
Reach (dB) 24
Reach (km) 80
Wavelength (nm) 1550
Connector LC Duplex
