Fiberworks 4 ch. DWDM Mux+Demux for C57

ITU ch. 14-17, 100GHz, Monitor ports, LC

Product nr: F-DMUX-4-C57-MLU
Product
DescriptionTechnical infoAccessoriesAlternatives
Description
Med denne multiplekseren kan man legge 4 DWDM-kanaler på en standard 1571 nm CWDM-kanal.

FEATURES
- Dense WDM in compliance with ITU-T G.694.1
- 4 DWDM channels 14-17 with 100 GHz spacing

- Two 2% monitor ports for easy troubleshooting
- Based on thin film optics with epoxy free optical path
- Protocol transparent (support 1G, 10G etc.)
- Two modules fit in 1U in 19" rack
- LC connectors

Technical info

Product information

Form factor Fiberworks
Fiber type SM
Line fiber Double (fiber pair, mux+demux)
Channel count 4
Add/drop Capabilities No, mux/demux only
Connector type Straight (UPC, PC)
Other features Monitor port
Customs classification codes
  • ECCN: EAR99
  • HS: 8517.62.0090
